Jewellery, Scientific

AB series

Overview

Precision Balance

Capacity：320g〜12000g／Readability：0.001g～0.1g

High precision weighing in affordable budget

Specifications

AB Series
Model nameAB323 / AB323CEAB623 / AB623CE
Capacity320g620g
Readability(d)0.001g0.001g
Verification intervals(e)0.01g0.01g
Accuracy classⅡⅡ
Repeatability0.001g0.001g
Linearity±0.003g±0.004g
Stabilization time3.0 sec.3.5 sec.
Pan size140mm dia
Dimentions(WDH)293×202×206mm (Including Windshield)
Windshield○○
AB Series (Large Capacity)
Model nameAB1202 / AB1202CEAB3202 / AB3202CEAB12001 / AB12001CE
Capacity1200g3200g12000g
Readability(d)0.01g0.01g0.1g
Verification intervals(e)0.1g0.1g1g
Accuracy classⅡⅡⅡ
Repeatability0.01g0.01g0.1g
Linearity±0.02g±0.03g±0.2g
Stabilization time3.0 sec.3.5 sec.3.0 sec.
Pan size190×190mm
Dimentions(WDH)293×196×89mm
Windshield×××
ABR Series
Model nameAB323R / AB323RCEAB623R / AB623RCE
Capacity320g620g
Readability(d)0.001g0.001g
Verification intervals(e)0.01g0.01g
Accuracy classⅡⅡ
Repeatability0.001g0.001g
Linearity±0.003g±0.004g
Stabilization time3.0 sec.3.5 sec.
Pan size140mm dia
Dimentions(WDH)293×202×206mm (Including Windshield)
Windshield○○
ABR Series (Large Capacity)
Model nameAB1202R / AB1202RCEAB3202R / AB3202RCEAB12001R / AB12001RCE
Capacity1200g3200g12000g
Readability(d)0.01g0.01g0.1g
Verification intervals(e)0.1g0.1g1g
Accuracy classⅡⅡⅡ
Repeatability0.01g0.01g0.1g
Linearity±0.02g±0.03g±0.2g
Stabilization time3.0 sec.3.5 sec.3.0 sec.
Pan size190×190mm
Dimentions(WDH)293×196×89mm
Windshield×××

Features

  • High precision, basic applications, affordable budget
  • User friendly operation
  • Highly visible, LCD display with back light
  • Connection to outside devices through standard RS232C output
