Laser Engraving Machine
ELITE
Overview
ELITE is a high-end, compact, portable laser marking machine used for customizations, marking on gift articles, jewellery, buttons, USB sticks etc.
Specifications
| Unit | ||
| Laser | Fiber Laser | |
| Laser Power | W | 20 | 30 | 50 |
| Mode of Operation | Pulsed | |
| Max. Peak Power | kW | > 7.5 |
| Operating Temperature | Up to 40 °C | |
| Lens | F - Theta | |
| Wave Length | nm | λ = 1060 ±10 |
| Marking Area | mm | 150 x 150 / 100 x 100 / 70 x 70 (Optional) |
| Repeatability | micron | ≤80 |
| Beam (Ø) ** | micron | 30 – 60 |
| Working Area | mm | 320 x 200 |
| Overall Size (L * B * H) | mm | 850 x 500 x 700 |
| Gross Weight | kg | 65 |
| Actuator Travel (Motorized) | mm | 80 |
| Maximum Job Load | kg | With Space = 10 & Without Space = 15 |
| Software | Mark - Pro |
Features
- Aesthetic Jewellery Marking
- Quick and Efficient
- Intuitively Process Varied Sizes
- Simple Operation
- Camera Vision Driven Marking / TTL Technology
- Superficial Design Fume Extractor
- Motorized Axis for Faster Focusing
